• In accordance with API 526, ASME SEC.I

• Available with threaded connection (BSP and NTP) or flanged connection
• Full nozzle
• Valve size: up to 2”
• Balanced bellows
• Forge body and bonnet

• In accordance with API 526, ASME Sec.VIII
• • Temperature: -29 to 427
• • Pressure range: 0.3 to 412 bar
• • Full nozzle
• • Valve size: 1”x2” to 8”x10”
• • Orifice: D to T

• Temperature: -46 to 260

• Pressure rage: 0.35 to 102 bar

• Full nozzle

• Valve size: up to 1”

• Conventional

• Cast or forge body and bonnet

• Temperature: 40 to150°C

• Valve Size:  from 1" up to 4"

• pressure range:0.35 bar to 40 bar

• Variety of type : conventional , bellows & balanced piston

• Pilot operated safety valves
• • In accordance with API 526, ASME Sec.VIII
• • Temperature: -268 to 260
• • Pressure range: 0.5 to 413 bar
• • Valve size: 1”x2” to 8”x10”
• • Orifice: D to T

• Non-API design
• • Orifice: D to U with customized orifices
• • Pressure range up to 412bar
• • Designed to meet the needs of the customer’s site
• • Cast, forge or bulk design for body and bonnet
• • Semi/full nozzle
• • Conventional/balanced bellows

• • Temperature: -46 to 260
• • Pressure range: 0.35 to 102 bar
• • Full nozzle
• • Valve size: up to 1”
• • Bellows
• • Cast or forge body and bonnet
